competitive pricing, equipped with silent 120mm fans.
The power supplies are fully built from steel, coated in elegant black, and
equipped with extra-long native cables. The EON Series runs quietly and provides
its power with all essential protection and safety features.
Total power | 700 W |
AC input voltage | 200 - 240 V |
AC input frequency | 50 Hz |
Input current | 5.5 A |
Maximum input current (@220V) | 5.5 A |
Power factor | 0.9 |
Power Factor Correction (PFC) type | Active |
Combined power (-12V) | 4.8 W |
Max output current (+3.3V) | 20 A |
Max output current (+12V1) | 53 A |
Max output current (+5V) | 20 A |
Max output current (-12V) | 0.4 A |
Max output current (+5Vsb) | 2.5 A |
Power protection features | Surge and inrush, Surge protection, Short circuit |
Motherboard power connector | 20+4 pin ATX |
Motherboard power cable length | 65 cm |
Number of SATA power connectors | 4 |
SATA power cable length | 450,600,750 mm |
Peripheral (Molex) power cable length | 450,600,750 mm |
EPS power connector (4+4 pin) | Yes |
PCI Express power connectors (6+2 pin) | 2 |
CPU power connector (4+4 pin) | Yes |
ATX power connector (20+4 pin) | Yes |
Cabling type | Non-Modular |
80 PLUS certification | 80 PLUS |
Supported motherboard form factors | ATX |
Purpose | PC/Server |
Power supply unit (PSU) form factor | ATX |
ATX version | 2.3 |
Product colour | Black |
Fan diameter | 12 cm |
On/off switch | Yes |
Width | 150 mm |
Depth | 140 mm |
Height | 86 mm |
Weight | 1.4 kg |
Warranty period | 2 year(s) |
