Built for amazing views, the View 170 WS ARGB Snow Micro Chassis is an M-ATX case accented with stylish wood elements, tempered glass front and left panels, and comes with two 120mm ARGB Lite Reverse Fan on motherboard side and one 120mm ARGB Lite Fan at the rear.
View 170 WS ARGB Snow Micro Chassis
Built for amazing views, the View 170 WS ARGB Snow Micro Chassis is an M-ATX case accented with stylish wood elements, featuring tempered glass front and left panels, and comes with two 120mm ARGB Lite Reverse Fan on motherboard side and one 120mm ARGB Lite Fan pre-installed. Its RGB lighting can be controlled by motherboard software from ASUS, GIGABYTE, MSI, and ASRock. Additionally, up to seven 120mm fans can be installed in the chassis, and up to a 280mm/240mm radiator can be placed on the top of the View 170 WS ARGB Snow Micro Chassis.
Tempered Glass Front and Left Panels
The View 170 WS ARGB Snow Micro Chassis is designed for better visibility, allowing users to enjoy their system through the tempered glass front and left panels.
Up to a 280mm/240mm Radiator
Providing good cooling support, users can choose to place a 280mm/240mm radiator on the top of the View 170 WS ARGB Snow Micro Chassis.
Pre-installed Fan System
The View 170 WS ARGB Snow Micro Chassis comes with two 120mm ARGB Lite Reverse Fan on the motherboard side and one 120mm ARGB Lite Fan at the rear. It’s fascinating lighting effects can be controlled by motherboard software from ASUS, GIGABYTE, MSI, and ASRock.
Flexibility to Build Your Ideal PC
The View 170 WS ARGB Snow Micro Chassis offers good expandability. It can support a CPU cooler with a maximum height of 160mm, GPU placement up to 340mm in length, a power supply up to 180mm in length. Optimized for excellent cooling performance, the case comes with two 120mm ARGB Lite Reverse Fan on motherboard side and one 120mm ARGB Lite Fan at the rear, and up to seven 120mm fans can be installed. For radiator compatibility, it can support up to a 280mm/240mm on top, giving more options for high-end expansion!
How Much Storage Is Totally Up To You
For storage compatibility, the View 170 WS ARGB Snow Micro Chassis gives maximum support of up to two 2.5‘’ SSDs and one 3.5‘’ HDD in total.
Handy I/O Ports
Two USB 3.0 ports and an HD audio port are located on the top panel for instant access when needed.
Sync with Motherboard RGB Software
Designed to synchronize with ASUS Aura Sync, GIGABYTE RGB Fusion, MSI Mystic Light Sync, and ASRock Polychrome. It supports motherboards with a 5V addressable RGB header, allowing you to control the lights directly from the software mentioned above without installing any extra lighting software or controllers. For more details, please visit ASUS, GIGABYTE, MSI, and ASRock official websites.
Design
Material: SPCC, Tempered glass
Form factor: Micro Tower
Type: PC
Product colour: White
Supported motherboard form factors: micro ATX, Mini-ITX
Number of 3.5" bays: 1
Number of 2.5" bays: 2
Number of internal 3.5" bays: 1
Number of expansion slots: 4
Feature: Side window
Suitable for: Gaming
Feature: Illumination
Illumination colour: Multi
Illumination location: Case fans
Feature: Tempered glass panel(s)
Feature: Reset button
Feature: On/off button
Feature: LED indicators
Maximum CPU cooler height: 16 cm
Maximum graphics card length: 34 cm
Maximum PSU length: 18 cm
Power supply
Power supply location: Bottom
Supported power supply form factors: PS2
Ports & interfaces
Feature: Audio input
Feature: Audio output
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Cooling
Side fans installed: 2x 120 mm
Number of side fans supported (max): 2
Side fans diameters supported: 120 mm
Rear fans installed: 1x 120 mm
Number of rear fans supported (max): 1
Rear fans diameters supported: 120 mm
Number of top fans supported (max): 2
Top fans diameters supported: 120,140 mm
Number of bottom fans supported (max): 2
Bottom fans diameters supported: 120 mm
Feature: Liquid cooling capability
Rear radiator sizes supported: 120 mm
Top radiator sizes supported: 120,140,240,280 mm
Storage
Supported HDD sizes: 2.5,3.5"
Packaging content
Feature: Manual
Weight & dimensions
Width: 214 mm
Depth: 381.4 mm
Height: 438 mm
Thermaltake View 170 WS ARGB Snow. Form factor: Micro Tower, Type: PC, Product colour: White. Power supply location: Bottom, Supported power supply form factors: PS2. Side fans installed: 2x 120 mm, Side fans diameters supported: 120 mm, Rear fans installed: 1x 120 mm. Supported HDD sizes: 2.5,3.5". Width: 214 mm, Depth: 381.4 mm, Height: 438 mm
Thermaltake
MBR CODE - CA-1Z4-00M6WN-WS
EAN - 4711658545633
