Elevate your computing experience with GIGABYTE's renowned motherboard series: AORUS, AERO, and GIGABYTE. Featuring innovative designs and advanced features, these boards offer exceptional performance and reliability. Whether you're a gamer, content creator, or professional, our series cater to your needs, ensuring uncompromising quality and cutting-edge
Processor manufacturer |
AMD |
Processor socket |
Socket AM5 |
Compatible processor series |
AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series |
Supported processor sockets |
Socket AM5 |
Supported memory types |
DDR5-SDRAM |
Number of memory slots |
4 |
Memory slots type |
DIMM |
Memory channels |
Dual-channel |
ECC сompatibility |
Non-ECC |
Supported memory clock speeds |
8200,8000,7950,7900,7800,7600,7400,7200,7000,6800,6600,6400,6200,6000,5800,5600,5200,4800,4400 MHz |
Supported memory clock speed (max) |
8200 MHz |
Maximum internal memory |
256 GB |
Unbuffered memory |
Yes |
Maximum internal memory per slot |
64 GB |
Supported storage drive types |
HDD & SSD |
Supported storage drive interfaces |
M.2, PCI Express 4.0, PCI Express 5.0, SATA III |
Number of HDDs supported |
4 |
Number of storage drives supported |
6 |
RAID support |
Yes |
RAID levels |
0, 1, 10 |
Parallel processing technology support |
Not supported |
Maximum resolution |
3840 x 2160 pixels |
DirectX version |
12.0 |
USB 2.0 connectors |
2 |
USB 3.2 Gen 1 (3.1 Gen 1) connectors |
1 |
USB 3.2 Gen 2x2 connectors |
1 |
Number of SATA III connectors |
4 |
Front panel audio connector |
Yes |
Front panel connector |
Yes |
ATX Power connector (24-pin) |
Yes |
CPU fan connector |
Yes |
Number of CPU fan connectors |
2 |
Number of chassis fan connectors |
4 |
EPS power connector (8-pin) |
Yes |
Number of EPS power connectors (8-pin) |
1 |
TPM connector |
Yes |
12V power connector |
Yes |
Number of water pump connectors |
2 |
RGB LED pin header |
Yes |
Number of RGB LED pin headers |
4 |
USB 2.0 ports quantity |
4 |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
5 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
2 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
1 |
Ethernet LAN (RJ-45) ports |
1 |
HDMI ports quantity |
1 |
HDMI version |
1.4 |
DisplayPorts quantity |
1 |
DisplayPort version |
1.4 |
Headphone outputs |
1 |
Line-in |
Yes |
S/PDIF out port |
Yes |
Digital audio optical out |
1 |
WiFi-AP antenna jack |
2 |
Ethernet LAN |
Yes |
Ethernet interface type |
2.5 Gigabit Ethernet |
LAN controller |
Realtek RTL8125 |
Wi-Fi |
Yes |
Top Wi-Fi standard |
Wi-Fi 6E (802.11ax) |
Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax) |
WLAN controller model |
Realtek RTL8852CE |
Bluetooth |
Yes |
Bluetooth version |
5.3 |
Motherboard chipset |
AMD B850 |
Audio chip |
Realtek ALC1220-VB |
Audio output channels |
7.1 channels |
Product colour |
Black |
PC health monitoring |
Fan, Temperature, Voltage, Water cooling |
Component for |
PC |
Motherboard form factor |
micro ATX |
Motherboard chipset family |
AMD |
Cooling type |
Passive |
Power source type |
ATX |
Windows operating systems supported |
Windows 10 x64, Windows 11 x64 |
PCI Express x16 (Gen 3.x) slots |
1 |
PCI Express x16 (Gen 5.x) slots |
1 |
Number of M.2 (M) slots |
2 |
1st M.2 largest key size |
25110 |
1st M.2 highest PCI Express generation |
5.0 |
2nd M.2 largest key size |
22110 |
2nd M.2 highest PCI Express generation |
4.0 |
BIOS type |
UEFI AMI |
BIOS memory size |
256 Mbit |
ACPI version |
5.0 |
Clear CMOS jumper |
Yes |
Desktop Management Interface (DMI) version |
2.7 |
System Management BIOS (SMBIOS) version |
2.7 |
Products per shipping (inner) case |
1 pc(s) |
Battery weight |
3 g |
Lithium weight per battery |
0.07 g |
Number of battery cells |
1 |
Battery technology |
Lithium-Manganese Dioxide (LiMnO2) |
Battery type |
CR2032 |
Package width |
270 mm |
Package depth |
268 mm |
Package height |
68 mm |
Package weight |
1.97 kg |
Width |
244 mm |
Depth |
244 mm |
Height |
35 mm |
Batteries included |
Yes |
Antenna included |
Yes |
Screws included |
Yes |
Bundled software |
Norton® Internet Security (OEM version)
LAN bandwidth management software |
Weight |
1.78 kg |
Warranty period |
3 year(s) |
